12A DC-DC Step Down Buck Converter Low Ripple High Power-12A

Name: 12A DC-DC Step Down Buck Converter Low Ripple High Power-12A
SKU: E-509
Price: 500.00 INR
Availability: InStock

SKU E-509

Be the first to leave a review.

₹500.00 +GST

Shipping & Delivery

The delivery time will depend on the product availability as well as your location. Pan India delivery will take around 3 to 4 days.

Returns & Exchanges

We do not offer any returns. If you genuinely have received a faulty product, please contact us.

Description

Input voltage: 5-40V;Output voltage: 1.2-30V adjustable，1.2-30V fixed output
Output Current: 12A MAX (rated 8A, peak 12A) 100W enhance heat dissipation of up to 200W,Working temperature: -40 to 85 degrees
Operating frequency: 180KHz;Conversion efficiency: up to 95%
Short circuit protection: Yes (limit current 12A)
Overtemperature protection: (automatically shut off the output after overtemperature)
Input Reverse Polarity Protection: None
Installation: four 3mm screws (not included)
Connection: terminals, solderless, V-IN is the input, V-OUT is the output, with wire output module housing.
Module size: 50mm * 50mm * 18mm
Application: This module can be used in batteries, power transformers, DIY adjustable power supply, 24V car T of the power supply, automotive LED lights with power, industrial Buck equipment, 12V t- 3.3V, 12V – 5V, 24V – 5V , 24V -12V, etc.
Package Included：1 x Buck Converter Module
Note:Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is /- 1-3 cm.
