Description
Micro 2 Pin On-Off Self Locking Switch
TC-60
ON-OFF function
Rating of 1A 30VDC/1A 250VAC
Contact resistance of 100mOhm max
Electrical life of >= 10,000 cycles
Dielectric strength of 500VAC 1 minute
Operating temperature range of -25C to 85C
Insulation resistance of 100mOhm min (500VDC)
Additional Information
Weight | 1.62 g |
---|
