Ai-Thinker/Lite Cell (HLT) Zigbee Module With Firmware LC-PZ2/PB01

The Ai-Thinker/Lite Cell (HLT) Zigbee Module is a compact SMD-20 wireless communication module designed for low-power Zigbee applications. Preloaded with LC-PZ2/PB01 firmware, it provides ready-to-use mesh networking and device-to-device communication. It supports multiple interfaces including GPIO, PWM, SPI, and ADC, making it highly versatile for embedded system integration.

This module offers a maximum transmit power of 10 dBm, ensuring reliable wireless communication in IoT, smart home, and industrial monitoring applications. Its surface-mount package allows easy integration into compact PCB layouts.

KEY FEATURES

• Zigbee modulation mode for wireless communication
• Preloaded firmware: LC-PZ2 / PB01
• Interfaces: GPIO, PWM, SPI, ADC
• Maximum transmit power: 10 dBm
• Compact SMD-20 package
• Low power consumption
• Suitable for IoT, smart home, and embedded applications

SPECIFICATIONS

• Modulation Mode = Zigbee
• Firmware = LC-PZ2 / PB01
• Maximum Transmit Power = 10 dBm
• Operating Frequency = 2.4 GHz ISM band
• Interfaces = GPIO / PWM / SPI / ADC
• Package Type = SMD-20
• Operating Voltage = 3.3V DC typical
• Communication Range = Up to 100 meters line-of-sight
• Current Consumption = TX: 40mA, RX: 30mA typical

INTERFACES

• VCC = Power supply input 3.3V
• GND = Ground
• GPIO = General purpose input/output pins
• PWM = Pulse width modulation output
• SPI = Serial peripheral interface
• ADC = Analog-to-digital input
• ANT = Antenna connection
