LM35D Analog Temperature Sensor Module (Precision Linear Analog Temperature Sensor)

The LM35D Analog Temperature Sensor Module is a precision temperature sensing module based on the LM35D integrated circuit, designed to provide a linear analog voltage output directly proportional to the measured temperature. Unlike thermistors, the LM35D does not require external calibration and delivers accurate temperature measurements with low self-heating characteristics. The module interfaces easily with the Analog-to-Digital Converter (ADC) inputs of microcontrollers such as Arduino, ESP32, STM32, and Raspberry Pi Pico, making it suitable for environmental monitoring, industrial control, laboratory experiments, and embedded system applications.

Key Features -

• Based on the LM35D precision analog temperature sensor IC

• Linear analog voltage output of 10mV per Degree C

• No external calibration required

• High accuracy temperature measurement with ±0.5C typical accuracy at 25C

• Wide operating voltage range from 4V to 30V DC

• Low self-heating for improved measurement stability

• Direct interface with microcontroller ADC inputs

• Compact PCB module for easy integration

• Suitable for continuous temperature monitoring applications

• Ideal for embedded systems, automation, and educational projects

Specifications -

• Product type - Analog Temperature Sensor Module

• Model - LM35D

• Main IC / Chipset - LM35D

• Operating voltage - 4V to 30V DC

• Temperature range - -55C to 150C

• Accuracy - ±0.5C typical at 25C

• Output type - Analog voltage

• Output scale - 10mV per Degree C

• Sensor type - Precision analog temperature sensor

• Package / Mounting type - PCB Module with Header Pins

• Operating temperature - -55C to 150C

• Additional features - Linear output, low self-heating, no external calibration required

Applications -

• Ambient temperature monitoring

• Weather and environmental monitoring systems

• Arduino and ESP32 temperature sensing projects

• Industrial temperature measurement and control

• Laboratory experiments and educational kits

• Home automation and HVAC systems

• Battery and power supply temperature monitoring

• Embedded systems and Internet of Things (IoT) applications
