JGA25-370 12V 170RPM DC Gear Motor with Encoder (Metal Gear Motor, Encoder Motor)

The JGA25-370 12V 170RPM DC Gear Motor with Encoder is a high-torque geared motor designed for robotics, automation systems, smart vehicles, position control, and industrial applications. Featuring durable metal gears, a built-in encoder, and a compact design, this motor provides accurate speed feedback and reliable low-speed operation for precision motion control projects.

Key Features -

• 12V DC operation

• 170RPM output speed

• Built-in encoder for speed feedback

• Durable metal gear construction

• 4mm output shaft

• Bidirectional rotation

• High torque performance

• Multiple protection features

Specifications -

• Product type - DC geared motor with encoder

• Model - JGA25-370

• Operating voltage - 12V DC

• Output speed - 170RPM

• Gear type - Reducer Gear

• Shaft diameter - 4mm

• Bearing type - Metal bush bearings

• Rotation direction - Bidirectional

• Encoder supply voltage - 3.3V to 5V

• Protection - Over-current, overload, over-temperature, and reverse polarity protection

Wiring Mode -

• Red - Motor Power Supply Positive (+)

• White - Motor Power Supply Negative (-)

• Blue - Encoder Power Supply Positive (+) (3.3V to 5V)

• Black - Encoder Power Supply Negative (-) (3.3V to 5V)

Applications -

• Robotics projects

• Smart vehicle platforms

• Industrial automation

• Position control systems

• Conveyor mechanisms

• Motion control applications

• DIY electronics projects
