OBD-II OBD2 16 Pin Female to Open End Cable (9.5 Inch)

The OBD-II OBD2 16 Pin Female to Open End Cable is designed for connecting an OBD2 diagnostic interface to custom electronic circuits, automotive test equipment, and vehicle communication systems. It features a standard 16-pin OBD2 female connector on one end and open wire ends on the other, allowing individual conductors to be connected according to the requirements of the application. The 9.5 inch cable length provides convenient access for automotive testing and development.

Key Features -

• Standard OBD-II OBD2 16-pin female connector

• Open wire ends for custom connections

• 9.5 inch cable length

• Suitable for automotive diagnostic and testing applications

• Enables access to individual OBD2 signal lines

• Useful for custom cable and interface development

Specifications -

• Product Type: OBD-II OBD2 Cable

• Connector Type: 16 Pin OBD2 Female to Open End

• Number of Connector Positions: 16

• Connector Gender: Female

• Cable Length: 9.5 Inch

• Cable Configuration: Female Connector to Open Wires

• Termination: Open Wire Ends

• Application: Automotive Diagnostics and Electronic Testing

• Housing Material: Plastic, verify manufacturer specifications

• Wire Gauge and Insulation: Refer to manufacturer specifications

Applications -

• OBD2 diagnostic equipment

• Automotive electronic testing

• Vehicle communication interface development

• ECU testing and development

• Automotive data acquisition

• Custom OBD2 cable assemblies

• Automotive embedded systems
