RJ45 8 Pin Vertical 180 Degree 8P8C Plastic Female Connector (PCB Mount Ethernet Socket)

The RJ45 8P8C Vertical Female Connector is designed to provide an Ethernet network connection on printed circuit boards. Featuring an 8-position, 8-contact interface and a vertical 180-degree orientation, this connector supports direct PCB mounting in compatible electronic equipment. Its plastic housing provides insulation and mechanical support for the internal contacts.

Key Features -

• RJ45 female connector with 8P8C configuration

• 8 positions and 8 electrical contacts

• Vertical 180-degree connector orientation

• Plastic housing for electrical insulation

• Designed for PCB mounting

• Suitable for compatible Ethernet network interfaces

• Compact design for electronic equipment and network devices

• Supports standard Ethernet cable connections through a compatible RJ45 plug

Specifications -

• Product Type: RJ45 Female Connector

• Connector Interface: RJ45

• Contact Configuration: 8P8C

• Number of Positions: 8

• Number of Contacts: 8

• Connector Gender: Female

• Orientation: Vertical, 180 Degrees

• Housing Material: Plastic

• Mounting Type: PCB Mount

• Termination Style: Verify manufacturer specification

• Shielding: Verify manufacturer specification

• Contact Plating: Verify manufacturer specification

• Supported Ethernet Category and Data Rate: Depends on the connector design and complete network interface

Applications -

• Ethernet network interface boards

• Routers and network switches

• Embedded systems and development boards

• Computer and communication equipment

• Industrial Ethernet devices

• Network interface circuit boards

• Electronic product development and repair
