22pF (220K) 3KV High Voltage Ceramic Disc Capacitor (Through Hole Radial Lead Capacitor)

The 22pF (220K) 3KV High Voltage Ceramic Disc Capacitor is a compact through-hole capacitor designed for high-voltage filtering, coupling, tuning, and pulse applications. Featuring a capacitance of 22pF, a 3KV DC voltage rating, and a ceramic dielectric, it delivers stable electrical performance and excellent insulation for high-voltage electronic circuits and Printed Circuit Board assemblies.

Key Features -

• 22pF capacitance value

• 3KV DC rated operating voltage

• High voltage ceramic disc construction

• Through Hole mounting

• Radial lead configuration

• ±20% capacitance tolerance

• Stable electrical performance

• High dielectric strength

• Low leakage current

• Suitable for high-voltage electronic applications

Specifications -

• Product Type - High Voltage Ceramic Disc Capacitor

• Capacitance - 22pF

• Capacitor Code - 220K

• Operating Voltage - 3KV DC

• Tolerance - ±20%

• Dielectric Material - Ceramic

• Mounting Type - Through Hole

• Lead Type - Radial Leads

• Compatibility - Through Hole Printed Circuit Board assemblies

Applications -

• High-voltage power supplies

• Pulse circuits

• Resonant circuits

• Radio frequency circuits

• Signal coupling

• High-voltage filtering

• Oscillator circuits

• Test and measurement equipment

• Industrial electronic equipment

• Through Hole Printed Circuit Board assemblies
