10 Pin FRC/IDC Straight Male Box Header with Lock (5 x 2 Pin, 2.54 mm Pitch, Gray)

The 10 Pin FRC/IDC Straight Male Box Header is designed for reliable ribbon cable-to-PCB connections in electronic and embedded systems. It features a 5 x 2 pin configuration with a standard 2.54 mm pitch, straight through-hole mounting, and an integrated locking feature for secure mating with compatible IDC ribbon cable connectors. The gray insulated housing provides a compact and organized connector interface for multi-signal connections.

Key Features -

• 10-pin 5 x 2 configuration

• Standard 2.54 mm contact pitch

• Straight male box header design

• Through-hole PCB mounting

• Integrated locking feature for secure mating

• Compatible with suitable FRC and IDC ribbon cable connectors

• Gray insulated connector housing

• Suitable for multi-signal board-to-cable connections

Specifications -

• Product Type: FRC/IDC Box Header Connector

• Connector Configuration: 5 x 2

• Total Number of Pins: 10

• Pitch: 2.54 mm

• Connector Gender: Male

• Mounting Type: PCB Through-Hole Mount

• Orientation: Straight

• Termination Type: Through-Hole Solder

• Housing Colour: Gray

• Housing Material: Plastic

• Contact Material: Metal, exact composition to be verified

• Locking Feature: Yes

• Compatible Cable: 10-conductor FRC/IDC ribbon cable with matching pitch

• Voltage and Current Ratings: Refer to manufacturer specifications

Applications -

• Ribbon cable interconnections

• Embedded system interfaces

• Microcontroller development boards

• Computer and peripheral connections

• Industrial electronic control systems

• Communication and interface boards

• PCB-to-cable connections
