22K Ohm Resistor Network (9 Pin SIP, Single Inline Package)

The 22K Ohm resistor network is a compact resistor array designed to provide multiple resistance elements within a single package. Its 9 pin Single Inline Package (SIP) simplifies PCB assembly and reduces component count compared with using individual resistors. Depending on the specific network configuration, it can be used for pull up or pull down resistors, signal conditioning, and digital logic interfacing.

Key Features -

• Nominal resistance of 22K Ohm

• 9 pin Single Inline Package

• Multiple resistors integrated into one component

• Compact design for space efficient PCB layouts

• Simplifies circuit assembly and reduces component count

• Suitable for digital signal interfacing and biasing applications

Specifications -

• Component Type: Resistor Network

• Resistance: 22K Ohm

• Number of Pins: 9

• Package: SIP

• Mounting Type: Through Hole

• Resistor Configuration: Depends on the specific network variant

• Tolerance: Verify the manufacturer's datasheet

• Power Rating: Verify the manufacturer's datasheet

• Pin Arrangement: Confirm the common pin and internal resistor connections before use

Applications -

• Microcontroller input pull up and pull down circuits

• Digital logic interfacing

• Signal conditioning circuits

• Input biasing networks

• Embedded electronic systems

• PCB designs requiring multiple resistors in a compact package
