74150 DIP IC 16 Input Data Selector Multiplexer (74150 IC)

The 74150 is a 16 input data selector multiplexer integrated circuit designed for digital data routing applications. It selects one of sixteen input data lines and routes the selected input to a single output based on the binary address applied to the select inputs.

This IC belongs to the TTL logic family and is widely used in digital systems where multiple input signals need to be routed through a single output line. It is commonly used in data selection circuits communication systems and microprocessor based applications. The DIP package makes it suitable for breadboard prototyping and PCB based digital electronics designs.

Key Features

• 16 input data selector multiplexer
• Single output data selection from multiple inputs
• Four select control inputs for channel selection
• Suitable for digital data routing applications
• TTL compatible logic levels
• High speed data selection operation
• DIP package suitable for prototyping and PCB mounting

Specifications

• IC Model = 74150
• Logic Type = 16 input multiplexer
• Number Of Data Inputs = 16
• Number Of Select Inputs = 4
• Output Type = Single output
• Logic Family = TTL
• Package Type = DIP
• Operating Voltage = 4.75V to 5.25V
• Application = Data selection routing and digital control circuits

Interfaces

• D0 = Data input 0
• D1 = Data input 1
• D2 = Data input 2
• D3 = Data input 3
• D4 = Data input 4
• D5 = Data input 5
• D6 = Data input 6
• D7 = Data input 7
• D8 = Data input 8
• D9 = Data input 9
• D10 = Data input 10
• D11 = Data input 11
• D12 = Data input 12
• D13 = Data input 13
• D14 = Data input 14
• D15 = Data input 15
• S0 = Select input bit 0
• S1 = Select input bit 1
• S2 = Select input bit 2
• S3 = Select input bit 3
• Y = Multiplexer output
• VCC = Power supply
• GND = Ground
