74LS74 Dual D-Type Positive Edge-Triggered Flip-Flops IC DIP-16 (TTL Logic Integrated Circuit)

The 74LS74 is a dual D-type positive edge-triggered flip-flop integrated circuit designed for high-speed digital logic applications. It contains two independent D-type flip-flops, each featuring preset and clear inputs for flexible control. Manufactured using Low-Power Schottky (LS) TTL technology, the IC offers fast switching performance with low power consumption and is fully compatible with standard TTL logic levels. Packaged in a DIP-16 through-hole package, the 74LS74 is widely used in digital storage, counters, frequency division, registers, and sequential logic circuits.

Key Features -

• Dual D-type positive edge-triggered flip-flops

• Independent preset and clear inputs

• High-speed TTL logic operation

• Low power consumption

• Compatible with standard TTL logic levels

• Reliable data storage and synchronization

• Through-hole DIP-16 package

• Suitable for sequential logic circuits

• Fast switching performance

• Easy integration into digital systems

Specifications -

• Product Type - Dual D-Type Flip-Flop Integrated Circuit

• Model - 74LS74

• Manufacturer - FSC

• Logic Family - Low-Power Schottky TTL (LS)

• Flip-Flops - 2 Independent D-Type

• Trigger Type - Positive Edge Triggered

• Supply Voltage (VCC) - Up to 7V

• Input Voltage (VI) - Up to 7V

• Number of Pins - 16

• Package Type - DIP-16

• Mounting Type - Through Hole

• Logic Compatibility - Standard TTL

Applications -

• Digital data storage

• Shift registers

• Binary counters

• Frequency divider circuits

• Sequential logic systems

• Timing and synchronization circuits

• Embedded electronics

• Digital control systems

• Educational electronics projects

• Printed Circuit Board digital designs
