74LVC245APW Octal Bus Transceiver IC SMD TSSOP20 (74LVC245APW TSSOP 20 IC)
The 74LVC245APW Octal Bus Transceiver IC SMD TSSOP20 is a high speed CMOS logic IC featuring eight non inverting bidirectional transceiver channels with 3 state outputs. It is designed for controlled data transfer between buses in low voltage digital systems. The TSSOP20 SMD package provides compact size, efficient PCB space usage, and reliable performance in dense circuit designs.
The 74LVC245APW SMD IC is widely used in India for embedded systems, microcontroller interfacing, memory communication, and industrial electronics. It is valued for its bidirectional data flow control, low power consumption, and high speed signal handling in modern applications.
Key Features
- Octal Bus Transceiver: Eight bidirectional data channels
- Bidirectional Control: Direction control for data flow
- 3 State Outputs: High impedance mode for bus sharing
- Output Enable Control: Allows bus isolation
- Low Voltage CMOS Operation: Suitable for modern digital systems
- SMD TSSOP20 Package: Compact and high density mounting
Specifications
- IC Type: Octal Bus Transceiver IC
- Logic Family: LVC CMOS Logic
- Number of Channels: 8
- Direction Control: Yes
- Output Type: 3 State Output
- Operating Voltage: Low voltage CMOS range
- High Speed Operation: Fast signal transmission
- Package Type: TSSOP 20 SMD
- Mounting Type: Surface Mount
- Applications: Bus interfacing data transfer memory communication microcontroller systems embedded systems industrial electronics
Pinout Configuration TSSOP20 Layout
- Bidirectional data pins for eight channels
- Direction control pin for data flow selection
- Output enable control pin
- VCC supply pin
- GND ground pin
