ADS1220IPWR TSSOP-16 24-Bit Analog to Digital Converter IC (ADS1220IPWR)
The ADS1220IPWR is a high precision 24-bit Analog to Digital Converter IC designed for sensor measurement, industrial control, and data acquisition applications. It features a programmable gain amplifier, low noise performance, and SPI communication interface, making it suitable for precision weighing systems, temperature sensing, pressure monitoring, and embedded electronics projects.
Key Features -
- 24-bit high resolution analog to digital converter
- Integrated programmable gain amplifier
- SPI serial communication interface
- TSSOP-16 surface mount package
- Low noise and high precision measurement performance
Specifications -
- IC type / Product type - 24-Bit Analog to Digital Converter IC
- Logic family / Component type - Precision Data Converter IC
- Package type - TSSOP-16 SMD IC
- Supply voltage - Approx 2.3V to 5.5V DC
- Input voltage - Differential analog input channels
- Output voltage - Digital output data through SPI interface
- Current rating - Low power operation suitable for sensor systems
- Frequency / propagation delay - Programmable data rates up to approx 2000 samples per second
- Operating temperature - Approx -40 to +125 degree C
- Additional important specifications - Integrated PGA, internal voltage reference, temperature sensor support, low noise operation, selectable gain settings, SPI compatible interface
Applications -
- Precision weighing systems
- Temperature measurement circuits
- Pressure and sensor monitoring systems
- Industrial automation equipment
- Embedded electronics and data acquisition projects
Pinout Configuration -
- Pin 1 - Analog input channel
- Pin 2 - Analog input channel
- Pin 3 - Ground connection
- Additional pins - SPI communication pins, reference voltage pins, power supply pins, data ready output pin, clock input pins
