TB6560 Stepper Motor Driver Module (TB6560 CNC Stepper Motor Controller)

The TB6560 Stepper Motor Driver Module is a high-performance motor control solution designed for driving bipolar stepper motors in CNC machines, automation systems, robotics, and motion control applications. Based on the TB6560 driver IC, it provides adjustable current control, microstepping functionality, and reliable protection features, ensuring smooth and precise motor operation.

Key Features -

• Based on TB6560 stepper motor driver IC

• Supports bipolar stepper motors

• Adjustable output current settings

• Microstepping control capability

• High torque and smooth motor operation

• Built-in protection functions

• Suitable for CNC and automation applications

Specifications -

• Product type - Stepper motor driver module

• Driver IC - TB6560

• Motor type - Bipolar stepper motor

• Control signals - STEP, DIR, and ENABLE

• Microstepping - Multiple microstep settings supported

• Current control - Adjustable output current

• Mounting type - PCB module

• Cooling type - Heatsink assisted cooling

• Application type - Motion and motor control

• Additional features - Overcurrent protection, thermal protection, and stable motor driving performance

 NPN Transistor

• Collector-Emitter Voltage (VCEO) - 40V

• Collector-Base Voltage (VCBO) - 40V

• Collector Current (IC) - 8A

• Peak Collector Current - 10A

• Power Dissipation (PW) - 70W

Applications -

• CNC router machines

• CNC engraving systems

• 3D printing projects

• Robotics and automation

• Linear motion control systems

• Industrial machinery

• DIY motion control projects
