BISS0001 SOP-16 PIR Motion Detector Controller IC (BISS0001)
The BISS0001 is a PIR Motion Detector Controller IC designed for passive infrared sensing and motion detection applications. It is commonly used in automatic lighting systems, motion activated alarms, security devices, and occupancy sensing circuits due to its low power consumption and integrated signal processing functionality.
Key Features -
- PIR motion detector controller IC
- Integrated motion signal processing circuit
- Low power consumption operation
- SOP-16 surface mount package
- Adjustable delay time and sensitivity support
Specifications -
- IC type / Product type - PIR Motion Detector Controller IC
- Logic family / Component type - Sensor Control IC
- Package type - SOP-16 SMD IC
- Supply voltage - Approx 3V to 5V DC
- Input voltage - PIR sensor signal input
- Output voltage - Digital motion detection output
- Current rating - Low operating current consumption
- Frequency / propagation delay - Adjustable timing through external RC components
- Operating temperature - Approx -20 to +70 degree C
- Additional important specifications - Dual operational amplifier stages, retriggerable and non-retriggerable modes, adjustable sensitivity and output delay timing
Applications -
- PIR motion detection systems
- Automatic lighting control circuits
- Security alarm systems
- Occupancy sensing devices
- Smart home automation projects
Pinout Configuration -
- Pin 1 - Operational amplifier input
- Pin 2 - Operational amplifier input
- Pin 3 - Timing control connection
- Additional pins - PIR sensor input pins, output control pin, mode selection pins, timing resistor and capacitor pins, VDD supply pin, VSS ground pin
