D30XT80-SBD Bridge Rectifier 30A 800V (Single Phase Bridge Rectifier)

The D30XT80-SBD Bridge Rectifier is a high-performance single-phase full-wave bridge rectifier designed for efficient AC to DC conversion in high-power industrial and commercial applications. Rated for a maximum average forward current of 30A and a peak reverse voltage of 800V, it is ideal for switching mode power supplies, battery chargers, motor drives, welding equipment, industrial automation systems, and power conversion circuits. It is housed in a compact TSB 5-pin SIP package for efficient heat dissipation and reliable long-term operation.

Key Features -

• Single-phase full-wave bridge rectifier

• Maximum average forward current of 30A

• Peak reverse voltage of 800V

• Compact TSB 5-pin SIP package

• High surge current capability

• Low forward voltage drop

• Reliable AC to DC conversion

• High thermal performance

• Suitable for continuous industrial operation

Specifications -

• Product Type: Bridge Rectifier

• Model: D30XT80-SBD

• Package: TSB 5-Pin SIP

• Rectifier Type: Single-Phase Full-Wave Bridge Rectifier

• Maximum Average Forward Current: 30A

• Peak Reverse Voltage: 800V

• Mounting Type: Through Hole

• Number of Pins: 5

• Maximum Surge Forward Current: 300A

• Maximum Junction Temperature: 150 C

Applications -

• AC to DC power supplies

• Switching mode power supplies (SMPS)

• Battery chargers

• Industrial power supplies

• Motor drive circuits

• Welding equipment

• UPS and inverter systems

• Industrial automation equipment

• DIY power electronics
