LM224 SOIC-14 Quad Operational Amplifier IC (LM224)
The LM224 is a quad operational amplifier IC designed for general purpose analog signal processing, amplification, filtering, and control applications. It contains four independent operational amplifiers in a single SOIC-14 package, making it suitable for industrial electronics, sensor signal conditioning, active filters, and embedded analog circuits.
Key Features -
- Quad operational amplifier IC
- Four independent op-amp channels
- Wide supply voltage range
- SOIC-14 surface mount package
- Low power analog operation
Specifications -
- IC type / Product type - Quad Operational Amplifier IC
- Logic family / Component type - Linear Analog IC
- Package type - SOIC-14 SMD IC
- Supply voltage - Approx 3V to 32V DC or +/-1.5V to +/-16V DC
- Input voltage - Differential analog input
- Output voltage - Analog amplified output
- Current rating - Low power analog operation
- Frequency / propagation delay - Approx 1MHz gain bandwidth product
- Operating temperature - Approx -25°C to +85°C
- Additional important specifications - Four independent operational amplifiers, low input bias current, wide common mode range, internal frequency compensation, short circuit protection support
Applications -
- Sensor signal conditioning circuits
- Active filter applications
- Industrial control systems
- Audio and analog processing circuits
- Embedded analog electronics projects
Pinout Configuration -
- Pin 1 - Amplifier output
- Pin 2 - Inverting input
- Pin 3 - Non-inverting input
- Additional pins - Additional amplifier input and output pins, positive supply pin, negative supply pin, ground connection
