PIC16F628A-I/SO SOIC-18 8-Bit Microcontroller IC with Flash Memory (PIC16F628A-I/SO)
The PIC16F628A-I/SO is an 8-bit microcontroller IC designed for embedded control, automation, communication systems, and general purpose electronic applications. It features onboard Flash memory, EEPROM data memory, timers, USART communication support, and programmable GPIO pins in a compact SOIC-18 package.
Key Features -
- 8-bit microcontroller IC
- Integrated Flash and EEPROM memory
- Built-in USART communication support
- SOIC-18 surface mount package
- Low power embedded operation
Specifications -
- IC type / Product type - 8-Bit Microcontroller IC
- Logic family / Component type - Embedded Microcontroller IC
- Package type - SOIC-18 SMD IC
- Supply voltage - Approx 2V to 5.5V DC
- Input voltage - CMOS compatible digital input levels
- Output voltage - CMOS logic output levels
- Current rating - Low power microcontroller operation
- Frequency / propagation delay - Operating frequency up to approx 20MHz with external oscillator
- Operating temperature - Approx -40 to +85 degree C
- Additional important specifications - Flash program memory, EEPROM data memory, USART communication interface, timers, comparator modules, watchdog timer support, programmable GPIO pins
Applications -
- Embedded control systems
- Serial communication applications
- Industrial automation equipment
- Consumer electronic devices
- Microcontroller based development projects
Pinout Configuration -
- Pin 1 - Master clear or reset pin
- Pin 2 - GPIO or oscillator input pin
- Pin 3 - GPIO or oscillator output pin
- Additional pins - USART communication pins, timer pins, comparator input pins, power supply pins, programmable GPIO pins, ground connection
