RF1221TI LPCC-48 RF Transceiver IC (TRF1221TI)
The TRF1221TI is an RF transceiver IC designed for wireless communication, RF signal processing, and industrial radio frequency applications. It integrates transmitter and receiver functions with high frequency operation, making it suitable for wireless data communication systems, RF modules, telemetry equipment, and embedded RF designs.
Key Features -
- Integrated RF transceiver IC
- High frequency wireless communication support
- Transmitter and receiver functionality
- LPCC-48 surface mount package
- Low power RF operation
Specifications -
- IC type / Product type - RF Transceiver IC
- Logic family / Component type - Wireless Communication IC
- Package type - LPCC-48 SMD IC
- Supply voltage - Approx 2.7V to 3.6V DC
- Input voltage - RF and digital control input signals
- Output voltage - RF signal output and digital interface levels
- Current rating - Low power RF operation
- Frequency / propagation delay - High frequency RF communication support
- Operating temperature - Approx -40 to +85 degree C
- Additional important specifications - Integrated RF transmitter and receiver, PLL frequency synthesis support, digital control interface, low noise RF performance, programmable communication features
Applications -
- Wireless communication systems
- RF data transmission modules
- Industrial telemetry equipment
- Embedded RF control systems
- Wireless sensor networks
Pinout Configuration -
- Pin 1 - RF input or output pin
- Pin 2 - Power supply pin
- Pin 3 - Ground connection
- Additional pins - Digital communication interface pins, oscillator pins, control pins, RF matching pins, programmable GPIO pins
