WCS1600 Hall Effect Current Sensor Module (AC/DC Analog Current Sensor Module)

The WCS1600 Current Sensor Module is a Hall effect-based current sensing module designed for accurate measurement of both AC and DC current in electrical and electronic systems. It provides galvanic isolation between the measured current path and the output circuit, ensuring safe and reliable operation while protecting connected microcontrollers. The module generates an analog voltage proportional to the measured current, making it suitable for Arduino, ESP32, ESP8266, STM32, Raspberry Pi (with ADC), and other embedded platforms. It is ideal for power monitoring, motor control, battery management systems, inverters, and energy measurement applications.

Key Features -

• Hall effect current sensing technology

• Measures both AC and DC current

• Galvanic isolation between input and output

• Analog voltage output

• High sensitivity and measurement accuracy

• Low power consumption

• Compact PCB module

• Easy interface with microcontrollers

• Suitable for power monitoring applications

• Reliable and stable performance

Specifications -

• Product type - Hall Effect Current Sensor Module

• Sensor model - WCS1600

• Sensor type - Hall Effect Current Sensor

• Operating voltage - 5V DC

• Current measurement range - Model Dependent (Up to 35A Typical)

• Output type - Analog Voltage

• Sensitivity - Model Dependent (mV/A)

• Isolation type - Galvanic Isolation

• Response type - Real-Time Current Measurement

• Operating temperature - 0C to 70C

Applications -

• Power monitoring systems

• Motor current measurement

• Battery management systems

• Solar power systems

• Inverters and UPS

• Industrial automation

• Energy metering

• Embedded electronics projects
