Description
5V 700mA 3.5W Isolation Power Supply Module AC-DC Step Down Module
E-1006
Output indicator: SMD LED
Full load power: <4W
No-load power: <0.05W
Working temperature: -20~70
Test resistance: 7 ohms (4.9V) for 5V
Output power: 3.5W, efficiency is about 80%
Input voltage range: AC50V-277V / DC70V-390V
Output current: 5VmA-700mA, enters constant current mode when fully loaded
Output protection: overvoltage, overcurrent, over temperature, short circuit protection, etc.
Output characteristics: Multiple voltage modules can be used in parallel to meet the needs of small current and large current
Output voltage: 5V+-0.15v no load and full load, light load minus 0.1V, rebound when heavy load, 50% load ripple 60mV
Capacitance temperature is 105° 10,000 hours, more than 5 years at 70°, and about 20-50 years at room temperature (not recommended for use above 70°).
Additional Information
| Weight | 5.72 g |
|---|
