Assembled DIY Geiger Counter Module with GM Tube for Nuclear Radiation Detection (Beta, Gamma and X-Ray Detector)

The Assembled DIY Geiger Counter Module is a radiation detection device designed to detect ionizing radiation using a compatible Geiger-Muller (GM) tube. It can detect radiation events from beta particles, gamma rays, and X-rays, depending on the installed tube and its specifications. The module converts detected events into electrical pulses and audible clicks, making it suitable for educational experiments, electronics projects, and radiation monitoring demonstrations. The assembled design simplifies integration into compatible electronic systems.

Key Features -

• Designed for detecting ionizing radiation using a compatible GM tube

• Supports detection of beta, gamma, and X-ray radiation, depending on the tube

• Assembled module for convenient integration

• Audible click indication for detected radiation events

• Pulse output for microcontroller interfacing and data logging

• Integrated high-voltage generation circuit for the GM tube

• Suitable for educational experiments and laboratory demonstrations

• Compact design for DIY electronics projects

Specifications -

• Product Type: Geiger Counter Radiation Detector Module

• Detection Principle: Geiger-Muller Radiation Detection

• Tube Type: Compatible GM tube; verify exact model

• Detectable Radiation: Beta, gamma, and X-rays, depending on tube specifications

• Operating Voltage: 5V to 12V DC, depending on module variant

• High-Voltage Output: Generated internally for GM tube operation

• Output Type: Electrical pulse signal and audible indication

• Sensitivity: Depends on the installed GM tube and module design

• Board Type: Assembled Radiation Detector Module

• Tube Inclusion: Verify package contents

Pin Configuration -

• VCC: DC power supply input within the specified module voltage range

• GND: Ground connection

• Pulse Output: Electrical pulse signal corresponding to detected events

• Speaker/Buzzer Output: Audible indication, if provided on the module

• GM Tube Terminals: Connections for the compatible Geiger-Muller tube

Applications -

• Educational nuclear radiation experiments

• DIY Geiger counter projects

• Radiation detection demonstrations

• Environmental radiation monitoring experiments

• Microcontroller-based radiation logging

• Electronics and physics laboratory projects

• Radiation event counting and analysis
