AVR ON16 Plus Serial ISP Programmer Board

The AVR ON16 Plus Serial ISP Programmer Board is designed for programming AVR microcontrollers using the in system programming method. It allows firmware to be uploaded directly to AVR chips through the ISP interface without removing the microcontroller from the target circuit.

This board connects to a computer through a serial interface and supports reliable programming of various AVR microcontrollers used in embedded system development. It is suitable for laboratory use educational experiments and embedded development projects involving AVR based controllers.

Key Features

• In system programmer for AVR microcontrollers
• Supports serial ISP programming interface
• Suitable for programming AVR microcontroller devices
• Reliable firmware uploading and debugging support
• Compact board suitable for development and laboratory use
• Easy connection to target circuits through ISP header

Specifications

• Programmer Type = AVR ISP programmer
• Programming Method = In system programming
• Communication Interface = Serial interface
• Supported Devices = AVR microcontrollers
• Board Type = Development programmer board
• Application = Firmware programming for AVR microcontrollers

Interfaces

• VCC = Power supply for target device
• GND = Ground
• MOSI = Master out slave in programming line
• MISO = Master in slave out programming line
• SCK = Serial clock for programming
• RESET = Target device reset line
• RX = Serial receive from computer
• TX = Serial transmit to computer
