PCB Mountable Micro SMPS-SO12V300 -12V 300mA (Isolated Power Supply Module)
The PCB Mountable Micro SMPS-SO12V300 is a compact isolated switching power supply module designed to provide a stable -12V DC output from a wide AC input range. It supports an output current of up to 300mA and is designed for direct PCB mounting in electronic circuits.
The module is suitable for generating negative voltage rails in operational amplifier circuits, analog electronics, signal conditioning, instrumentation, and embedded systems. Its compact switching design provides efficient AC to DC conversion while maintaining electrical isolation between the input and output.
KEY FEATURES -
- Regulated -12V DC output
- Output current up to 300mA
- Wide AC input voltage range
- Isolated SMPS design
- Compact PCB mountable construction
- Efficient switching power conversion
- Stable regulated output
- Suitable for negative voltage rail generation
- Ideal for embedded and industrial electronics
SPECIFICATIONS -
- Model = SO12V300
- Input Voltage = 85-265V AC
- Output Voltage = -12V DC
- Output Current = 300mA max
- Output Power = 3.6W
- Isolation Type = Galvanic isolation
- Conversion Type = Switching regulator SMPS
- Mounting Type = PCB through hole
- Output Type = Regulated DC
APPLICATIONS -
- Operational amplifier circuits
- Analog signal conditioning
- Negative voltage rail generation
- Instrumentation equipment
- Embedded electronic systems
- Industrial control circuits
- PCB power supply design
- Mixed-signal electronic circuits
- DIY power supply projects
