PIC 18F 16F UDB Shield Mini Development Board Without IC (PIC Programmer Board)

The PIC 18F 16F UDB Shield Mini Development Board Without IC is a compact development platform designed for compatible PIC 18F and PIC 16F series microcontrollers. The board is supplied without a microcontroller IC, allowing users to install a compatible device according to their development requirements.

It provides essential circuitry and interfaces for programming, testing, and prototyping PIC based embedded systems. The compact design makes it suitable for laboratory work, educational projects, and embedded system development.

Key Features -

• Compatible with PIC 18F and PIC 16F series microcontrollers

• Supplied without microcontroller IC

• Compact mini development board design

• Onboard voltage regulation

• Reset switch and user input buttons

• LED indicators for testing and development

• Expansion headers for I/O connections

• ICSP programming interface

Specifications -

• Compatible MCU Series = PIC 18F/PIC 16F

• Microcontroller IC = Not included

• Power Input = 5V DC

• Logic Level = 5V typical

• Oscillator Support = External crystal support

• Programming Interface = ICSP header

• Board Type = Mini PIC development board

Applications -

• PIC microcontroller development

• Embedded system prototyping

• Microcontroller programming and testing

• Educational electronics projects

• Laboratory development

• PIC based automation projects
