PIC 18F 16F Development Board UDB Shield Without IC

The PIC 18F 16F Development Board UDB Shield Without IC is a universal development platform designed for PIC 18F and PIC 16F series microcontrollers. The board is supplied without the microcontroller IC, allowing users to install their required compatible PIC device.

The board provides essential peripherals and interface connectors to simplify firmware development, testing, and debugging. It is suitable for educational use, embedded system development, and prototyping applications.

Key Features

• Compatible with PIC 18F and PIC 16F series
• Supplied without microcontroller IC
• Onboard power supply regulation
• Crystal oscillator support
• Reset and user input switches
• LED indicators for testing
• Expansion headers for I O access

Specifications

• Compatible MCU Series = PIC 18F 16F
• Power Input = 5V DC
• Logic Level = 5V typical
• Oscillator Support = External crystal
• Programming Interface = ICSP header
• Board Type = Universal development board

Interfaces

• VCC = 5V power input
• GND = Ground
• ICSP Header = In circuit programming interface
• PORT Pins = Microcontroller I O access
• Reset Switch = System reset control
• LED Pins = Status and test indicators
