TP4056 1.2A Li-Ion Battery Charging Module with Micro USB (Current Protection)

The TP4056 Li-Ion Battery Charging Module is a compact charging board designed for safely charging single-cell 3.7V Li-Ion and Li-Po rechargeable batteries. Based on the TP4056 linear battery charging IC, the module provides a constant current/constant voltage (CC/CV) charging algorithm for efficient battery charging. It features a Micro USB input for convenient power from USB adapters, power banks, or computer USB ports, along with built-in overcurrent and thermal protection for reliable operation.

This charging module is widely used in portable electronics, DIY battery packs, power banks, wearable devices, IoT projects, robotics, and embedded systems requiring a safe and simple single-cell lithium battery charging solution.

Key Features -

• Based on TP4056 lithium battery charging IC

• Supports single-cell 3.7V Li-Ion and Li-Po batteries

• Maximum charging current up to 1.2A

• Micro USB power input

• Constant Current / Constant Voltage (CC/CV) charging

• Built-in overcurrent protection

• Thermal protection for safe operation

• Automatic charge termination at full charge

• Charging and fully charged status indicators

• Compact and easy-to-integrate PCB module

Specifications -

• Product type - Li-Ion Battery Charging Module

• Charging IC - TP4056

• Battery type - Single-Cell Li-Ion / Li-Po Rechargeable Battery

• Nominal battery voltage - 3.7V

• Full charge voltage - 4.2V ±1%

• Input voltage - 5V DC (Micro USB)

• Maximum charging current - Up to 1.2A

• Charging method - Constant Current / Constant Voltage (CC/CV)

• Protection features - Overcurrent and Thermal Protection

• Mounting type - PCB Module

Applications -

• DIY battery-powered projects

• Portable electronic devices

• Power bank projects

• Arduino and ESP32 projects

• IoT devices

• Wearable electronics

• Rechargeable LED lighting

• Embedded system power supplies

• Robotics projects

• DIY electronics and battery management
