TTP224 4-Way Capacitive Touch Switch Module

The TTP224 4-Way Capacitive Touch Switch Module is a touch input board that provides four independent capacitive touch keys. It uses the TTP224 capacitive touch sensor IC to detect finger touch, converting touch events into digital outputs without mechanical buttons. The board is suitable for low power touch control interfaces in embedded systems.

This module is ideal for home automation panels, touch user interfaces, access control, interactive installations, and microcontroller based projects where compact touch inputs replace traditional switches. The touch sensing provides reliable performance and easy interfacing with digital logic systems.

KEY FEATURES

• Four capacitive touch inputs
• No mechanical buttons required
• Digital output signals
• Low power capacitive sensing
• Compact PCB module design
• Easy integration with microcontrollers
• LED indicator for touch status
• Suitable for touch control panels

SPECIFICATIONS

• Sensor IC = TTP224 capacitive touch controller
• Number of Channels = 4 touch inputs
• Output Type = Digital logic outputs
• Operating Voltage = Compatible DC logic voltage
• Sensitivity = Capacitive touch detection
• Response Time = Fast touch detection
• Mounting Type = PCB module
• Application = Touch interface/control systems

INTERFACES

• VCC = Power supply positive
• GND = Ground
• OUT1 = Touch key 1 digital output
• OUT2 = Touch key 2 digital output
• OUT3 = Touch key 3 digital output
• OUT4 = Touch key 4 digital output
