USB Logic Analyzer 24MHz 8-Channel Debug Tool (MCU ARM FPGA DSP Protocol Analyzer)

The USB Logic Analyzer 24MHz 8-Channel is a compact digital debugging and signal analysis tool designed for capturing, monitoring, and decoding digital signals in embedded systems and electronic circuits. With 8 input channels and a maximum sampling rate of 24MHz, it enables real-time analysis of digital waveforms and communication protocols through a USB connection to a computer.

Ideal for MCU, ARM, FPGA, DSP, Arduino, ESP32, STM32, Raspberry Pi, and other embedded development platforms, this logic analyzer supports protocol decoding and accurate timing analysis, making it an essential tool for debugging digital interfaces, firmware development, and hardware verification.

Key Features -

• 8-channel digital logic signal acquisition

• Maximum sampling rate up to 24MHz

• High-speed USB interface for PC connectivity

• Real-time waveform capture and display

• Supports multiple communication protocol decoding

• Accurate timing and signal analysis

• Compact and lightweight USB design

• Compatible with MCU, ARM, FPGA, and DSP development

• Easy integration with PC analysis software

• Ideal for debugging embedded systems and digital circuits

Specifications -

• Product type - USB Logic Analyzer

• Channel count - 8 Channels

• Maximum sampling frequency - 24MHz

• Signal type - Digital Logic Signals

• Interface - USB

• Input type - Logic Level Inputs

• Protocol support - Multiple Digital Communication Protocols

• Software support - PC Signal Capture and Analysis Software

• Mounting type - External USB Module

• Application - Digital Signal Analysis and Hardware Debugging

Applications -

• MCU firmware debugging

• Arduino and ESP32 development

• STM32 and ARM debugging

• FPGA and CPLD verification

• DSP signal analysis

• I2C, SPI, UART protocol decoding

• Embedded system development

• Digital electronics testing

• Educational electronics laboratories

• DIY electronics and hardware troubleshooting
